Solenoid and Directional Valves

Technical specifications:

Model: 4V210-08

Valve type: 5/2 pneumatic solenoid valve

Voltage: AC 220V

Connection: PT 1/4

Exhaust ports: 1/8

Operating pressure: ~ 0.15 – 0.8 MPa

Maximum pressure: up to 1.0 MPa

Body material: Aluminium alloy

Seals: NBR

Operating medium: Filtered compressed air

Temperature range: from 0°C to +60°C

Control type: Solenoid

Weight: 0.220 kg.

Technical specifications:

Model: SAW2000-02A

Type: FR (Filter + Regulator)

Connection: PT 1/4

Gauge port: PT 1/8

Operating medium: Compressed air

Operating pressure: 0.05 – 0.85 MPa

Maximum pressure: 1.0 MPa

Filtration: 40 μm standard

Operating temperature: from 5°C to 60°C

Flow rate: approx. 550 L/min

Housing material: Aluminium alloy

Reservoir: Polycarbonate

Pressure gauge: included

Weight: 0.360 kg.

Technical specifications:

Models: SAC2000-02 / SAC2000-02A

Operating medium: Compressed air

Connection: PT 1/4″

Gauge port: PT 1/8

Operating pressure: 0.05 – 0.85 MPa

Maximum pressure: 1.0 MPa

Temperature range: from 5°C to 60°C

Construction: Metal housing + transparent bowl

Mounting: Wall-mounted or directly in pneumatic line

Weight: 0.640 kg.

👉 SAC-2000-02 (FR)

FR – filter + regulator (without lubricator)

Function: cleaning + pressure regulation

Suitable for: basic pneumatic systems where lubrication is not required

👉 SAC-2000-02A (FRL)

FRL – filter + regulator + lubricator

Function: cleaning + regulation + lubrication

Ideal for: pneumatic tools, cylinders, valves that require lubrication for longer life

👉 FRL is an abbreviation for:

F — Filter — cleaning air of moisture and solid particles

R — Regulator — stabilising operating pressure

L — Lubricator — dosing oil into the pneumatic air

Technical specifications:

Model: AC2000-01

Type: FRL (Filter + Regulator + Lubricator)

Connection: PT 1/8

Operating medium: Compressed air

Operating pressure: 0.05 – 0.85 MPa

Maximum pressure: 1.0 MPa

Temperature range: from 5°C to 60°C

Filtration: approx. 25 μm

Flow rate: approx. 500 L/min

Reservoir: Polycarbonate

Housing: Aluminium alloy

Weight: 0.620 kg.

Technical Specifications:

Model: SAC2010-02A

Operating Medium: Compressed Air

Connection: PT 1/4″

Gauge Port: PT 1/8

Operating Pressure: 0.05 – 0.85 MPa

Maximum Pressure: 1.0 MPa

Temperature Range: 5°C to 60°C

Construction: Metal Housing + Transparent Reservoir

Mounting: Wall or Directly in Pneumatic Line

Weight: 0.520 kg.

Technical specifications:

Model: SAR2000-02

Series: SAR (Relief type air pressure regulator)

Connection: PT 1/4

Gauge port: PT 1/8

Operating pressure: 0.05 – 0.85 MPa

Maximum pressure: 1 MPa

Operating temperature: from 5°C to 60°C

Operating medium: Compressed air

Body: Aluminium alloy

Flow rate: approx. 550 L/min (at 0.7 MPa)

Weight: 0.280 kg.

Technical specifications:

Model: 4M230-08E

Type: Pneumatic solenoid valve

Positions: 5/3 (5 ports, 3 positions)

Voltage: DC 24V

Connection: G 1/4

Operating medium: compressed air (filtered ~40 µm)

Operating pressure: ~ 0.15 – 0.8 MPa

Max. pressure: up to ~ 1.2 MPa

Operating temperature: -20°C to +70°C

Power consumption: ~ 3–5 W (DC24V)

Protection rating: IP65

Material: aluminium housing

Control type: pilot-operated

Weight: 0.370 kg.

Valve type: 2-position, 2-way solenoid valve (2/2)

Orifice size: 2.5 mm

Connection size: G1/4 ''

Working fluid viscosity: < 20CST

Operating pressure: 0 - 6.91 atm

Max. Pressure: 9.87 atm

Operating temperature: from -5° C to + 80^o C

Operating voltage: 12 V

Operating current: 0.5 A

Body material: Aluminium

Seal material: NBR (nitrile rubber) or other suitable material.

Weight: 0.135 kg.
