Cylinders

Main characteristics:

Series: DNC

Piston diameter: 50 mm

Type: Pneumatic cylinder (Air Cylinder)

Standard: ISO 6431

Action: Double Acting

Operating medium: Filtered compressed air

Body material: Aluminium alloy

Operating pressure: approx. 0.1 – 1.0 MPa

Maximum pressure: approx. 1.35 MPa

Operating temperature: approx. -5°C to +70°C

Movement speed: 50 – 800 mm/s

Cylinder stroke: This product is available in various configurations up to 2000 mm.

✔ Custom manufacturing with strokes up to 2000 mm is possible, as well as non-standard sizes according to your specific requirements.

If you need a size not included in the standard offerings, please contact our team or enter the desired length in the field below and add a model close to yours to the cart!

Main specifications:

Series: DNC

Piston bore: 63 mm

Type: Pneumatic cylinder (Air Cylinder)

Standard: ISO 6431

Action: Double Acting

Operating medium: Filtered compressed air

Body material: Aluminium alloy

Operating pressure: approx. 0.1 – 1.0 MPa

Maximum pressure: approx. 1.35 MPa

Operating temperature: approx. -5°C to +70°C

Movement speed: 50 – 800 mm/s

Cylinder stroke: This product is available in various configurations up to 2000 mm.

✔ Custom manufacturing available for strokes up to 2000 mm, as well as non-standard sizes according to your specific requirements.

If you require a size not included in the standard offerings, please contact our team or enter the desired length in the field below and add a model close to yours to the cart!
