Single-channel frequency generator 1Hz-150kHz, with frequency adjustment and PWM

Single-channel frequency generator is used to generate rectangular pulses with a frequency of 1Hz to 150kHz. The frequency and PWM duty cycle are controlled by a potentiometer. The operating mode is changed via the potentiometer's button function. There are two operating modes – Normal and Precision. A small display is available, showing the frequency and PWM duty cycle. The module is connected via screw terminals.

Available:

- input terminal: V + and V- , which provide power to the board

- output terminal: PWM and GND, through which the generated signal is output. The signal amplitude is equal to the input voltage amplitude.

Advantages:

• Secure mounting by inserting into a rectangular slot and snapping in

• Easy adjustment of frequency and pulse duty cycle

• Two operating modes – normal and precision

• Compact module size allows for easy integration into devices

Applications:

• Generating signals with various frequencies

• Generating signals with different duty cycles – e.g., for transistor control – dimming, motor speed regulation

• Generating rectangular pulses for STEP signal for drivers

• Industrial applications
