Industrial Buttons and Switches Series XB2 (22mm)
Technical specifications:
Series: XB2 (metal series)
Mounting diameter: Ø22 mm
Rated voltage: Up to 660V AC / 440V DC
Rated current: 10A
Contact system: Modular (replaceable NO/NC blocks)
Protection rating: IP40 / IP65 (with protective cover)
Mechanical life: ≥ 1,000,000 cycles
Body material: Metal (chrome-plated zinc) and non-flammable polymer
Certificates: CE, IEC 60947-5-1
Model specifications:
|
Model
|
Actuator type
|
Colour
|
Contacts
|
Function
|
Weight
|
|
XB2-BC31
|
Button "Convex" (Bulgy Head) |
Green (Ø40mm) |
1NO |
Spring return |
0.085 kg. |
|
XB2-BSS42
|
Button "Mushroom" |
Red (Ø40mm) |
1NC |
Latching + Twist to release |
0.085 kg. |
|
XB2-BJ21
|
Rotary selector switch |
Black (long handle) |
1NO |
2 positions (0-1) |
0.080 kg. |
|
XB2-BA42
|
Flat button (Flush) |
Red |
1NC |
Spring return |
0.060 kg. |
|
XB2-BA61
|
Flat button (Flush) |
Blue |
1NO |
Spring return |
0.060 kg. |
The industrial components of the XB2 series are designed for controlling magnetic starters, contactors, relays, and other electrical circuits. Thanks to their robust metal housing, they are extremely resistant to mechanical shocks and harsh operating conditions. The modular design allows for easy replacement of contact elements and quick mounting on control panels, consoles, and electrical boards.
Each device in the series consists of an actuator head (button or switch), a metal flange, and a contact section. This ensures reliable operation and a long service life in industrial automation systems.
✅ Applications:
Electrical panels
Machinery and production lines
Automation
Control panels
Safety systems
✅ Advantages:
Standard size
High reliability
Easy installation
Wide choice of colours and functions
Compatible contact blocks
